ECG Machine
MT ECG 180
18-Channel Electrocardiograph System
The MT ECG 180 is a high-performance 18-lead electrocardiograph system designed for accurate ECG acquisition, seamless workflow, and intelligent management in hospitals, clinics, and diagnostic centres.
Key Features
❤️
Advanced ECG/18-Lead Performance
- Simultaneous 18-Lead ECG Acquisition
- Supports 18-Lead & Cabrera Lead Display
- High-Quality ECG Signal Processing
- Power Frequency Filter
- Baseline Filter
- EMG Filter
- Low-Pass Filter
- Auto & Manual ECG Recording Modes
- Automatic ECG Measurement & Interpretation
- Arrhythmia Detection & Rhythm Lead Selection
🖥️
Smart Display & Operation
- 10.1” High-Resolution Color LCD
- Multi-Language Interface
- Touch Screen + Function Button Operation
- 1280 × 800 Display Resolution
- Built-In Virtual Keyboard
- HR Value
- Battery Level
- Filter Status
- Sensitivity
- Measured Data & Interpretation
- Paper Speed
🖨️
Intelligent Printing System
- Built-in thermal printer
- Auto MxN, Auto MxN+1, MxN+2, MxN+3, Rhythm M line, and manual print modes
- Configurable waveform length, output parameters, diagnostic conclusion
- Auto arrhythmia print function and timed print function
- Printed content includes time, paper speed, sensitivity, patient information
📊
Accurate Measurement & Diagnosis
- Auto-measurement and auto-interpretation for routine ECG parameters
- Measures HR, PR Interval, P Duration, QRS Duration, T Duration, QT/QTc Interval
- P/QRS/T Axis, R(V5), S(V1), R(V5)+S(V1) amplitude, Cornell Index
💾
Memory & Data Management
- Built-in large-capacity memory stores at least 4000 medical records
- Review, inquire, modify, transmit, print and export historical records
- Export to dat, pdf, xml, bmp, jpeg, png formats
- LAN and USB cable transmission, auto upload cases and download reports
📡
Connectivity & Communication
- Wi-Fi wireless communication
- LAN and USB cable transmission
- Supports external USB keyboard, mouse, scanner, printer
- Automatic Case Upload & Report Download
🔋
Power & Reliability
- AC/DC Power Supply Support
- Built-in rechargeable lithium battery with charging circuit
- Perfect battery overcurrent and overvoltage protection
- Up to 10-hour standby in optimal DC state
- Continuous print more than 3 hours
- Record up to 1000 ECG waveforms (3s case)
- Lead-Off & Lack-of-Paper Alerts
